5080 Power Unit
5080 高压发生器是大部分Takker交流祛静电
系统的动力系统来源，它为祛静电帮，吹风机
及喷风枪等提供高压电源以产生电离子。
The 5080 Power Umit is the heart ofmost
F raser AC stratic eliminators In supplies the
high voltage which produces the ionisation in
most Takker Bars, Blowers.Guns etc.
5080产生一个受控制及安全的高压低流量电流
The 5080 produces high voltage, low cur
rent in a controlled andsafe way.
它最多可连接4个祛静电器
t has connections for up to four static eliminators.
结构： 喷粉涂层金属外壳
Construchion:Powder coated steel case.
输出： 5.5千伏于5毫安（最大）全密封输出线组
Output: 5.5kV at 5mA max.
Totally encapsulated windings..
输入：可按要求配置115伏 50/60Hz或 230伏 50/60Hz
或开关式双输入，主电源开关连保险IEC插座连2米主线
Input: 115V 50/60HZ or 230V 50/60Hz.Please specify
Switchable model also avaitable
Illyminated mains switch and fuse
IEC conneetor and 2m mains cable
负荷: 最大负荷:
2000棒及配置 祛静电帮及高压连接线最大总长度为12米
4000电离子喷风枪 一支枪加10米连线或两支枪加5米连线
Load Maximum load :
2000 Bar and derivatives: 12m of combined Bar and HT cable
4000 lonised Airgun: 1 Gun with 10m HT cable or 2 Guns with 5ms Htcable
安全
Safety 电流之上限为5毫安，具有安全过载保护，并在安全情况下自动重新起动
The design is cyrrent limited to 5mA ,lf more current is drawn then the windings will shut down.
Power will restart when the excessive load is removed.
|
